O.S. ENGINES OS-MAX-10FSR-C

Welcome to a tour through the results of the digital restoration of this 1.76 cc glow plug engine with cylindrical cross-ribbed extreme cooling head for RC cars.



An engine type of the FSR 1.76 cc series, which I used during the restoration of the GO-KART-10-GP and also digitally restored. This engine type was the standard recommendation for the kart.


Single-cylinder 2-stroke engine with glow plug ignition, Schnürle flushing, rotary valve crankshaft, side exhaust, crankshaft bearing as pressed-in bronze bushing, throttle carburetor with cylindrical throttle plug. Special cylindrical extreme cooling head with cross ribbing for air cooling.

Other engines

OS-MAX-10FSR-C

OS-MAX-10FP-M

OS-MAX-50SX-H-HYPER

OS-RE-49

OS-RE-49-PI

OS-RE-49-PI-GOLD

OS-RE-49-PI-II

OS-RE-49-PI-II-GOLD

OS-RE-98-PI-2C

OS-RE-147-PI-3C

OS-FS-20

HB-25H

OS-MAX-10FSR

OS-MAX-10FSR-S

OS-MAX-10FSR-B

OS-MAX-10FSR-C

OS-MAX-10FP-M

Displacement            1,76 ccm (0,107 cu.in)

Bore                            13,44 mm

Stroke                         12,40 mm

rpm range                  3.000...18.000 1/min

Performance              0,27 PS / 0,198 kW @ 17.000 1/min

Compression ratio    9.0:1 (full stroke)

Port timing                 Exhaust 146°, Transfer 124°, Third port 108°

Combustion type       2-stroke

Fuel                              Methanol, Oil, Nitromethane

>>> Blueprint

>>> Renderings

>>> CAD-Images & Illustrations







CAD-models            23.11.2023 - 24.11.2023

Rendering                30.04.2024 - 10.05.2024

Blueprint                  17.05.2024 - 19.05.2024

Step-model              _1486_os-max-10fsr-c.stp

Engine purchase     04.02.2023

Production date      approx. 1986
